Description

HTC 5G Hub Main Features

• 5G/4GX mobile multimedia smart hub for 5G/4G network
• Wi-Fi 6 technology and supports up to 20 Wi-Fi enabled devices
• 1GB Ethernet connection
• All-day battery life
• Allows smooth 4K video streaming and low latency for gaming
• Integrated display and speakers

HTC 5G Hub Specifications

Hardware

Qualcomm® Snapdragon™ 855 Octa-Core, with Snapdragon™ X50 5G Modem
Qualcomm®60GHz Wi-Fi chipset and Qualcomm® 2×2 Wi-Fi 6-ready chipset

Mobile Networks

Communication Standard: 3GPP Release 15
Supported Network: 5G, 4G
Network Mode: NSA
Network Frequency Band:
HTC 5G Hub in Europe
5G NR: band n78
4G LTE™: FDD: bands B1, B3, B7, B8, B32, B38, B40
HTC 5G Hub in USA
5G NR: band n78
4G LTE™: FDD bands 2, 3, 4, 5, 7, 8, 12, 13, 25, 26, 66, 71; TDD band 41
HTC 5G Hub in Australia
5G NR: band n41
4G LTE™: FDD bands 1, 2, 3, 4, 5, 7, 8, 12, 20, 28, 66; TDD bands 38, 41
5G Speeds:
Maximum 5G data rate 2.63 Gbps Down & 287 Mbps Up

Wi-Fi & LAN

WLAN Standard: 802.11 a / b / g / n / ac / ad
Maximum Wireless Transmission Rate:
HTC did not provide any information
WLAN Bands: 2,4, 5 and 60 GHz
Wi-Fi users: 20 Wi-Fi devices at the same time
WLAN guest access can be installed: k. A.
WLAN encryption standards: WPA, WPA2, WPS
Gigabit LAN: yes, 1 port Gigabit Ethernet
Bluetooth 5.0

Software

PLATFORM: Android™ 9.0
MEMORY

• RAM: 4 GB DDR4x
• ROM: 32 GB UFS, expandable up to 2TB

Support audio formats: .3gp, .mp4, .m4a, .aac, .ts, .flac, .mp3, .mid, .ogg, .mkv, .wav, .amr
Support video formats: .3gp, .mp4, .ts, .webm, .mkv
SENSORS: Motion G-Sensor
More Functions: 5G / 4G network access, Ethernet access, SMS service, firewall, MAC address filtering, Wi-Fi encryption authentication, VPN, IPv6 and IPv6 / IPv4 dual stack, battery management, etc.

Interface

DISPLAY: 5.0 inch, capacitive TFT touch screen, HD (720 x 1280 pixels)
Network Ports: 1 Gigabit Ethernet port, 1 USB-C port, 1 nano SIM and storage card tray, 1 DC charging port

Button: Recovery, Power button
Others: Microphones, Speakers
Battery Capacity: 7,660 mAh
Antenna slot: No slots for external antenna

Size

Dimensions: 129 x 100 x 43 mm
Weight: About 340 g
